Product Details:

Model: Tideace ARES EVO CR068

Material: T800 T1000 carbon fiber

Size: XXS/XS/S/M/L/XL

Bottom Bracket: T47 (86mm)

Spacer: 5mm*1 pcs, 10mm*1 pcs, 20mm*1 pcs

Tyre: Max 700*32C

Frame Weight: Frame(1100g), Fork(440g), Seatpost(150g), Size S Painted excluded the metal part.
Frame(980g), Fork(420g), Seatpost(149g), Size S in raw material excluded the metal part.

Seatpost: Dedicated flat aero seatpost 400mm length

Headset； 1-1/2 - 1-1/2

Fork: 39.8mm, Fit hubs(12*100mm)

For fork steerer tube diameter: 28.6mm

Rear Axle: 12*142mm

Brake Type: Flat mount 140mm Disc rotor, it is possible to install a 160mm rotor using a conversion seat.

Handlebar size: Please leave us a message of the size you need.

Package included: frame, fork, seatpost, handlebar, clamp, headset and thru axle
